XP1000 PCIe SSD
XP1000 PCIe SSD

XP1000 PCIe SSD

Applicable to high-performance PC devices.
Product Advantages

Additional channels and higher Flash FPS bring about high speed performance.
L1.2 low power consumption to achieve lower power consumption and longer service life.
Temperature control algorithm to balance speed and temperature during operation.

Consult Now GO
Product Parameter
Product Series Capacity Type Model Flash Memory Medium DRAM Operating Temperature Sequential Read/Write Speed Random Read/Write Speed (IOPS) Mean Time Between Failures (Hour) Warranty
XP1000 PCIe SSD 128GB M.2 2280 XP1000F128G 3D TLC DRAM-less 0℃~70°C Up to 3500MB/s / 3000MB/s Up to 327K / 294K 1500000 3 years
XP1000 PCIe SSD 256GB M.2 2280 XP1000F256G 3D TLC DRAM-less 0℃~70°C Up to 3500MB/s / 3000MB/s Up to 327K / 294K 1500000 3 years
XP1000 PCIe SSD 512GB M.2 2280 XP1000F512G 3D TLC DRAM-less 0℃~70°C Up to 3500MB/s / 3000MB/s Up to 327K / 294K 1500000 3 years
XP1000 PCIe SSD 1TB M.2 2280 XP1000F001T 3D TLC DRAM-less 0℃~70°C Up to 3500MB/s / 3000MB/s Up to 327K / 294K 1500000 3 years
XP1000 PCIe SSD 2TB M.2 2280 XP1000F002T 3D TLC DRAM-less 0℃~70°C Up to 3500MB/s / 3000MB/s Up to 327K / 294K 1500000 3 years
XP1000 PCIe SSD 128GB M.2 2230 XP1000F128G 3D TLC DRAM-less 0℃~70°C Up to 3500MB/s / 3000MB/s Up to 327K / 294K 1500000 3 years
XP1000 PCIe SSD 256GB M.2 2230 XP1000F256G 3D TLC DRAM-less 0℃~70°C Up to 3500MB/s / 3000MB/s Up to 327K / 294K 1500000 3 years
XP1000 PCIe SSD 512GB M.2 2230 XP1000F512G 3D TLC DRAM-less 0℃~70°C Up to 3500MB/s / 3000MB/s Up to 327K / 294K 1500000 3 years
Supports TRIM Function and S.M.A.R.T Function.
Product Features
  • 01
    PCIe Gen3x4 standard

  • 02
    NVMe 1.4 specification

  • 03
    HMB technology support

  • 04
    M.2 2280 interface

  • 05
    128GB, 256GB, 512GB, 1TB, 2TB and additional capacity options

  • 06
    Sequential read/write speed up to 3500MB/s/ 3000MB/s and random read/write rate up to 327K /294K IOPS

Application
  • Laptop

  • All-in-one machine

  • Desktop

  • Home IPC
