XP1000 PCIe SSD

Applicable to high-performance PC devices.

Product Advantages

Additional channels and higher Flash FPS bring about high speed performance.
L1.2 low power consumption to achieve lower power consumption and longer service life.
Temperature control algorithm to balance speed and temperature during operation.

Consult Now GO

back

Product Parameter

Product Series	PN	NAND Flash	Capacity	Type	DRAM	Operating Temperature	Sequential Read Speed*	Sequential Write Speed*	Random Read Speed (IOPS)*	Random Write Speed (IOPS)*	Mean Time Between Failures (Hour)
XP1000 PCIe SSD	FSB0C128G-C4C7200	3D TLC	128GB	M.2 2280	DRAM-less	0℃~70°C	1600MB/s	930MB/s	67K	170K	1.5 million hours
XP1000 PCIe SSD	FSB0C256G-C4C7200	3D TLC	256GB	M.2 2280	DRAM-less	0℃~70°C	3300MB/s	1800MB/s	130K	240K	1.5 million hours
XP1000 PCIe SSD	FSB0C512G-C4C7200	3D TLC	512GB	M.2 2280	DRAM-less	0℃~70°C	3400MB/s	2900MB/s	250K	260K	1.5 million hours
XP1000 PCIe SSD	FSB0C001T-C4C7200	3D TLC	1TB	M.2 2280	DRAM-less	0℃~70°C	3400MB/s	3000MB/s	330K	260K	1.5 million hours
XP1000 PCIe SSD	FSB0C002T-C4C7200	3D TLC	2TB	M.2 2280	DRAM-less	0℃~70°C	3400MB/s	3100MB/s	335K	260K	1.5 million hours
XP1000 PCIe SSD	FSB0C128G-C4H1400	3D TLC	128GB	M.2 2280	DRAM-less	0℃~70°C	1600MB/s	650MB/s	64K	140K	1.5 million hours
XP1000 PCIe SSD	FSB0C256G-C4H1400	3D TLC	256GB	M.2 2280	DRAM-less	0℃~70°C	3300MB/s	1300MB/s	126K	262K	1.5 million hours
XP1000 PCIe SSD	FSB0C512G-C4H1400	3D TLC	512GB	M.2 2280	DRAM-less	0℃~70°C	3400MB/s	2600MB/s	240K	286K	1.5 million hours
XP1000 PCIe SSD	FSB0C001T-C4H1400	3D TLC	1TB	M.2 2280		0℃~70°C	3500MB/s	3200MB/s	366K	280K	1.5 million hours

Supports TRIM Function and S.M.A.R.T Function.
*Data is sourced from internal testing of Longsys. The actual performance may vary between different devices.

Product Features

01
PCIe Gen3x4 standard
02
NVMe 1.4 specification
03
HMB technology support
04
M.2 2280 interface
05
128GB, 256GB, 512GB, 1TB, 2TB and additional capacity options
06
Sequential read/write speed up to 3500MB/s/ 3100MB/s and random read/write rate up to 360K /279K IOPS
